vS1665T


VS1665T

Photos may show optional equipment.

2024

VS1665T

w/ 40 ELHPT FourStroke Mercury®
Boat, Motor, & Trailer
View Price w/ Prep & Freight:
NO HAGGLE NO HASSLE® National Price
$23995
USD

Thriller of a tiller

For fisheries with a multitude of species, you need maximum versatility and the new VS1665 T delivers economical performance with ample amenities. Despite its 16' 3" size, the VS1665 T offers an abundance of space, strength and capability. A wide-open cockpit with movable seating gives space for tending trolling lines while the front deck is ideal for casting. It features a large storage with two accesses and a centered seat base. The timed and aerated livewell is at the rear of the deck adjacent trolling motor battery storage. Twin lockable 8' 6" rod boxes flank the cockpit, which is highlighted by a fiberglass gauge pod that houses a tach, twin USB ports and a 12V outlet, rocker switching and keyed ignition. Atop the pod sits the electronics of your choice, up to 7". Foot-activated trim switches are mounted in the cockpit just below the gauge pod. Behind the driver's seat is a folding casting deck that hides one or two 6-gallon fuel tanks and the cranking battery. A standard Ranger Trail® trailer is highlighted by new aluminum wheels. Every aspect of the new VS1665 T combines to make One Thriller of a Tiller.

Key Features

  • Fiberglass gauge pod houses switching, ignition, electronics, tach
  • 40HP rating
  • Premium movable seating
  • Twin 8' 6" lockable rod stows
  • Upright, level flotation
  • Standard Ranger Trail® trailer

Specifications

Length 4.95 m 16' 3''
Hull Length 4.95 m 16' 3''
Beam 2.03 m 80''
Max. Recommended HP 40 HP
Engine Shaft Length 50.8 cm 20''
Inside Depth 50.8 cm 20''
Hull Thickness 0.254 cm 0.1''
Chine Width 1.52 m 60''
Fuel Capacity 22.71 L 6 gal.
Livewell Capacity 75.7 L 20 gal.
Approximate Boat Weight 421.84 kg 930 lbs.
Rod Box Length - Port 2.59 m 8' 6''
Rod Box Length - Starboard 2.59 m 8' 6''
Max. Person Capacity 3 persons
Trailer GVWR 1358.51 kg 2995 lbs.
Approximate Length On Trailer w/ Motor Down (May vary with engine model and set-back plate) 6.45 m 21' 2''
Approx Length On Trailer w/Motor Down/Swing Tongue Open (May vary with engine model/set-back plate) 5.82 m 19' 1''
Width On Trailer 2.18 m 86''

Motor Options

AVAILABLE MOTOR
Mercury®
40 ELHPT FourStroke
$23995

USD
Select Dealer

Standard Features

Custom Details
  • Custom fitted marine upholstery- (3) matching fishing seats
  • Battery compartment w/ storage for (2) 6 gal. tanks and cranking battery
  • High gloss metallic paint with custom Ranger® graphics
  • Choice of colors: white, crystal red, charcoal metallic, midnight blue, carbon, fusion electra lime green, and fusion electra blue
  • Durable marine grade carpet
  • Non-skid marine-grade vinyl cockpit flooring
Electronics
  • Lowrance® HOOK2 4x at console
  • 8-gauge trolling motor wiring
  • Minn Kota® 55lb PowerDrive 54" DSC 12V trolling motor
  • 12V power outlet
  • Removable navigation lights
Power/Performance
  • Cranking battery and 1 trolling motor battery w/ tie-down
  • Prop (stainless standard at 115HP and up)
  • Power trim
  • Bow trim & navigation switches
  • Aerated livewell / baitwell on front deck
  • Custom fiberglass console w/ tachometer and gimbal mounted depthfinder
Safety/Comfort
  • Pull-up tie cleats (4)
  • All-aluminum floor & decks
  • Lockable storage
  • Upright, level flotation
  • Lockable rod storage
  • 5052 H34 marine grade aluminum
  • Foam-filled one-piece construction
  • Stainless steel boarding ladder
  • All welded aluminum transom
  • Remote drain plug
Trailer Features
  • Custom Ranger Trail® directional aluminum wheels
  • Retractable trailer tie downs
  • Swing jack
  • Custom swing-away tongue
  • Integrated load guides
  • NMMA® and NATM certified
  • Waterproof lights

Options
