Z518
Photos may show optional equipment.
2025
Z518
w/ 150 L Pro XS FourStroke Mercury®
Boat, Motor, & Trailer
| View Price w/ Prep & Freight: | Select Dealer |
|
PRICED TO BE YOURS®
|
$54995
USD
|
SCREAMING PERFORMANCE AND VALUE
In the 18-foot class, the Ranger® Z518 stands alone in terms of all-out performance, fishability, and features. With the standard 150-horsepower Mercury®, you’ll enjoy invigorating performance and economy, but opting for the 200-horse V8 FourStroke opens the door to a new level of all-out adrenaline-pumping exhilaration. And new for 2025 are standard push-to-close latches that eliminate the tripping hazard presented by twist-to-close latches.
We’ve maximized storage space up front with a pair of 8-foot rod boxes, a gelcoat-lined, insulated in-deck cooler and spacious starboard gear box. The oversize casting deck and 97-inch beam deliver a stout, stable platform. A foam-filled core and strategically placed pultruded fiberglass material deliver unshakable solidity and a one-piece feel throughout.
The console carries a full complement of precision gauges, the electronics of your choice up to 12” and stylish matte black accents. Integrated LED navigation lights, a recessed trolling motor pedal and SRS Soft-Ride™ seating round out this angler-centric rig that far outperforms its price tag. From daylight to dusk, the Ranger Z518 delivers features and value like none other.
Key Features
- Built to be Yours™ - Available with a wide array of custom-matched trolling motors, electronics, and accessories
- 200HP rating
- Maximized storage throughout, including 8' rod boxes
- Ranger Trail® trailer comes standard
- Recessed trolling motor pedal
- In-deck, gel-coated cooler
- Push-to-Close Latches
Specifications
| Length | 5.74 m | 18' 10'' |
| Beam | 2.46 m | 97'' |
| Max. Recommended HP | 200 HP | |
| Engine Shaft Length | 50.8 cm | 20'' |
| Inside Depth | 53.34 cm | 21'' |
| Fuel Capacity | 147.62 L | 39 gal. |
| Livewell Capacity | 90.84 L | 24 gal. |
| Total Person, Motor, Gear | 612.35 kg | 1350 lbs. |
| Approximate Boat Weight | 748.43 kg | 1650 lbs. |
| Rod Box Length - Port | 2.44 m | 8' |
| Rod Box Length - Center | 2.44 m | 8' |
| Max. Person Capacity | 4 persons | |
| Trailer GVWR | 1689.63 kg | 3725 lbs. |
| Approximate Length On Trailer w/ Motor Down (May vary with engine model and set-back plate) | 7.19 m | 23' 7'' |
| Approx Length On Trailer w/Motor Down/Swing Tongue Open (May vary with engine model/set-back plate) | 6.58 m | 21' 7'' |
| Width On Trailer | 2.59 m | 102'' |
Motor Options
| AVAILABLE MOTOR | |||||
|---|---|---|---|---|---|
| Mercury® | |||||
| 150 L Pro XS FourStroke |
$54995 USD
|
Select Dealer | |||
| 200 L FourStroke |
$58425 USD
|
Select Dealer | |||
| 200L Pro XS Torque Master |
$59655 USD
|
Select Dealer | |||
Standard Features
Custom Details
- Power Ventilation Rod Storage™
- Integrated center-storage rod & tackle management system
- Stainless steel push-to-close locking latches
- Carpeted rod storage w/ organizers
- Ranger® tournament measuring board integrated at front deck step
- Runnin' rod rack w/ retractable strap
- Remote drain plug
- Tool holders at bow and front deck step
- Molded-in driver / passenger footrests
- Integrated stainless steel cup holders
Electronics
- Built to be Yours™ - Available with a wide array of custom-matched trolling motors, electronics, and accessories
- Multi-function custom gauge package: speedometer, tachometer, fuel, trim, water pressure, temp & volt
- Easy-touch analog switching
- Keyed ignition
- Ranger® Umbilical™ dedicated bow-to-stern 6-gauge electronics wiring harness w/ 30A breaker
- Heavy Duty 6-gauge trolling motor wiring harness w/ 60A breaker
- Master Power on/off battery disconnect switch
- NOCO™ GB40 jump starter w/ on-board USB charging
- LED storage compartment lighting & LED courtesy & livewell lighting
- Integrated LED bow navigation lights & removable LED anchor light
- Lowrance® Eagle 5 at console
- On-Board Dual Pro® 15A x 3 Bank auto-detect lithium capable charger
Power/Performance
- MinnKota® Maxxum 70lb , 42" 24V trolling motor
- AGM Starting battery w/ tray
- (2) Trolling Battery trays (tray only)
- One-Piece-Feel Interloc Construction
- Pultruded Fiberglass Transom
- Integrated engine setback
- Hydraulic steering
- Recirculating aerated livewell w/ removable divider
- Venturi aeration system
- Recessed trolling motor foot pedal
- High performance stainless steel prop
- Foam-filled fiberglass stringer system
Safety/Comfort
- Upright Level Flotation exceeding all USCG & NMMA standards
- Fire extinguisher & horn
- Stainless steel seat bases
- Pop-up tie cleats
- Integrated grab handles
- Rite Track Keel®
- Automatic & manual bilge pumps
- Boarding ladder
Trailer Features
- Ranger® Boats Road Armor Equipped® trailer protectant coating
- 15" Machined/painted Raptor wheels w/ matching spare
- Ranger Trail® Vault® Hub lubrication system
- Fiberglass fenders w/ step pads
- Hydraulic surge disc brakes
- Swing-away tongue
- Integrated center-swing jack finished in black powdercoat
- Stainless steel ratcheting tie-downs
- LED lighting
- LED back-up lights
- NMMA®/NATM certified
